Description
- Permco Small Direct Mount Dump Pump DMD-400-20-ZR-200
- Pump and cylinder protected in the “Raise” and “Neutral” position of the spool
- Manual shift with full metering capabilities
- Built-in load check maintains dump body angle and is installed in the cylinder port for superior self-cleaning
- Direct Mount SAE "B" 4 Bolt
- Built-in direct acting relief valve set at factory
- 100% factory tested
- Flows of 29 GPM at 1800 RPM
- Pressures to 2500 PSI
- Speeds to 2400 RPM
- 2” gears 4.0 cu in. 65.5 cc
- High strength alloy steel gear and shaft set
- Neutral lock-out safety cap for use with pull-out cable
- 2 line for intermittent duty or 3 line for continuous duty systems
- Low weight: 36 lbs. for unit with remote mount configuration
Pressure balanced wear plates maintain high pump efficiency throughout all operating ranges
