Specifications
Eaton Medium Duty Fixed Motor – 74111-DAF-01 delivers reliable light-duty performance for compact mobile applications requiring fixed displacement. With 12.3 cm³/rev displacement and 606 in-lbs torque, this Series 741 axial piston motor powers compact machinery and mobile equipment.
Specifications:
- Displacement: 12.3 cm³/rev (0.75 in³/rev)
- Flow: 14.6 GPM
- Max. Speed: 4,500 RPM
- Torque: 606 in-lbs
- Pressure: 5,076 PSI
- Mount: SAE "A" 2-Bolt
- Shaft: 1" Keyed, Straight Shaft
- Ports: 1.0625-12 UN-2B SAE O-Ring - Opposite Sides
- Drain: 0.5625-18 UNF-2B SAE O-Ring - Upper Rear
- Model Code: AAVAEAA0B000A0B Eaton 74111-DAF-01
Common Applications:
- Compact mobile equipment
- Agricultural machinery
- Material handling equipment
