Specifications
- 2-bolt SAE-B Mounting flange, 7/8’’-13 spline shaft. Typical in a snowplow/sander application and used by Municipalities and Highway Maintenance.
- 1-1/4” NPT side ports
- 4.00 Cubic inch displacement, both sections
- Roller bearing design in a compact, small frame size
- Doweled and high-strength cast iron construction
- Low weight: 34.5 pounds with a 2” gear, Type II
- Flows up to 39 GPM
- Working pressure up to 3000 PSI
- Speeds up to 2400 RPM
- Special ring seals and pressure-balanced wear plates maintain high pump and motor
- efficiency throughout all operating ranges
- 100% factory tested per application specifications
- 7/8” 13 spline shaft
