Specifications
Char Lynn Hydraulic Motor – 119-1029 delivers reliable high-torque performance for demanding mobile and industrial applications requiring substantial power. With 479.5 cm³/r displacement and 13,050 in-lbs continuous torque, this 10,000 Series motor powers boring systems, metal forming equipment, and port machinery with exceptional efficiency and side-load capability.
Specifications:
- Displacement: 479.5 cm³/r (29.26 in³/r)
- Flow: 45 GPM Continuous (70 GPM Inter)
- Max. Speed: 354 RPM
- Torque: 13,050 in-lbs Continuous (17,410 in-lbs Inter)
- Mount: 4-Bolt Flange
- Shaft: 2.25" Keyed with 1/2"-20 Threaded Hole in End of Shaft
- Ports: #16 ORB Staggered
- Case Drain: #6 ORB
- Seals: Standard
- Genuine Char Lynn 119-1029
Common Applications:
- Boring
- Metal forming
- Port equipment
